Power Amplifier S2202
The power amplifier S2202 is designed for meeting every standard for professional amplification. Its powder coated steel face plates and heavy-duty steel chassis reflect the manufacturing quality within.
· Ultra light-weight
· Switched-mode power supply
· Heavy duty steel chassis
· CE approval for world-wide use
Technical specification
| Output Power (1 kHz, 1 % THD) | |
| 2 Ω - Single channel driven | 2200 W / channel |
| 2 Ω - Two channels driven | 1950 W / channel |
| 4 Ω - Single channel driven | 1480 W / channel |
| 4 Ω – Two channels driven | 1380 W / channel |
| 8 Ω - Single channel driven | 860 W / channel |
| 8 Ω - Two channels driven | 840 W / channel |
| Bridge - 8 Ω | 2760 W |
| Bridge - 4 Ω | 3900 W |
| THD - 1 kHz, 8 Ω | < 0,05 % |
| Frequency response | 20 Hz – 20 kHz +0 /-1 dB |
| - by 10 dB below nominal power | 20 Hz – 50 kHz +0 /-1 dB |
| Dmping Factoar, 8 Ω, 1kHz | > 200 |
| S/n Ratio | - 104 dB |
| S/n Ratio „A“ weighted | - 107 dB |
| Input Sensitivity – by nominal power / 8 Ω | 1,4 V / 26 dB |
| Input Impedance balanced | 20 kΩ |
| Slew Rate / 8 Ω | 20 V / μS |
| Subsonic filter | On / Off 40 Hz / 80 Hz |
| Controls | Front: Mains switch volume control (both channels) Rear: mode selection switch sensitivity and subs. filter switches |
| Indicators | Bridge, Limit In, - Out: yellow LED Protect : red LED Signal: green LED Power: blue LED |
| Cooling | step switched fan |
| Protects | short-circuit, thermal |
| Output circuit type | Class H |
| Power | 230V AC 50Hz, switched-mode PS |
| Dimensions | 483 x 88 x 370 mm (2U) |
| Weight | 12 kg |
©2008 Chevin Research. Product design and specifications may change without prior notice
Attachments: PDF document 175 Kb
