Rack Mount Amplifier S500L
The Chevin S500L is designed to meet every standard for distributed sound systems with isolated 50V, 70V and 100V outputs. Its controled cooling provides quiet operation. Powder coated steel face plates and steel chassis reflect the manufacturing quality within. It carries the CE approval for world-wide use.
Technical Specification
| Power output (1kHz at 1.0%THD) | 480 W |
| Input sensitivity 1 V | |
| Input impedance 20 kΩ | Balanced |
| THD 1 kHz / - 3dB | < 0.03 % |
| Frequency response - 3 dB | 20Hz - 20kHz |
| S/N Ratio | > 100 dB ( > 108 dB “A”) |
| Output [V] | 50 / 70 / 100 |
| Features | - thermal protection & automatic idling circuitry to insure stability and reliability against over-current and overheating, thermal protection circuitry is provided - cooling – variable speed fan |
| Inputs | - balanced XLR male + female for every channel |
| Indicators | - ON green LED - SIGNAL green LED for every channel - PEAK red LED for every channel - PROTECT red LED |
| Controls | - power switch On / Off - volume - level adjustment control for both channels |
| Power | AC ~ 230V / 120V 50 / 60 Hz |
| Requirements | |
| Rack | 2U |
| Dimensions | 485 x 88 x 370 mm |
| Weight | 15 kg |
©2008 Chevin Research. Product design and specifications may change without prior notice
