Rack Mount Amplifier S4120L
The Chevin S4120L is designed to meet every standard for distributed sound systems with isolated 50V, 70V and 100V outputs. Its controled cooling provides quiet operation. Powder coated steel face plates and heavy-duty steel chassis reflect the manufacturing quality within. It carries the CE approval for world-wide use.
Technical Specification
| Power output (1kHz at 1.0%THD) | 4 x 120 W |
| Input sensitivity | 1 V |
| Input impedance 20 kΩ | Balanced |
| THD 1 kHz / - 3dB | < 0.05 % |
| Frequency response - 3 dB | 20Hz - 20kHz |
| S/N Ratio | > 100 dB |
| “A” weighted | > 104 dB |
| Output [V] | 50 / 70 / 100 |
| Inputs | balanced XLR + female for every channel |
| Indicators | ON green LED SIGNAL green LED for every channel PROTECT red LED |
| Controls | power switch On / Off volume - level control for all channels |
| Power | AC ~ 230V / 120V 50 / 60 Hz |
| Requirements | |
| Dimensions | 483 x 88 x 360 mm (2U) |
| Weight | 13,6 kg |
©2008 Chevin Research. Product design and specifications may change without prior notice
Attachments: PDF document 237 Kb
